54.6V 2A / 3A Li-ion Battery Charger For Foldable Electric Kick
Scooter E-bike
| FEATURES |
| Universal AC input/Full range |
| No load power consumption<0.3W |
| High efficiency and reliability |
| Pass LPS |
| Plastic Case,2 Color LED loading indicator |
| Durable and well-made to guarantee long term use |
| ERP step 2 complaint |
|
| Model | Input Voltage Range | Output Voltage Range | Output Current Range |
| XYY84-420200 | AC100~240V | 3~48V | 0.1~6A |
| Input Characteristics |
| Input Voltage Range | AC100~240V |
| Rated Input Frequency | 50~60HZ |
| Input Current | 0.5a max At low line input and DC output full load |
| Output Characteristics |
| Rated Voltage | 42V |
| Efficiency | 79% Min. At 100vac input and output Max.Load 81% Min. At 240vac input and output Max.Load |
| OverShoot | 15% Max.When power supply at turn on or turn off |
| Protection |
| Over Voltage Protection | The battery charger will not be auto recovered when faults remove |
| Over Current Protection | The battery charger will be auto recovered when over current faults
remove |
| Short Circuit | The battery charger will be auto recovered when short circuit
faults remove |
| Environment |
| Operating temperature | 0℃~40℃ |
| Storage temperature | -20℃~85℃ |
| Relative Humidity | 5%~90% |
>>Suggested application:
mobile phone charger, phone charger, cell phone charger, travel
charger,MP3/MP4 player charger, digital cameras, TV power supply,
LCD power supply, video game player or small power electrical
equipment power supply,ect.
>>why choose us:
1. Quality control: You can be assured of the quality.
Because we tested one by one before send out the goods.
2 .Use the high quality and high capacity.
3. Long standby time,long lifespan.
4. Larger order can get big discount.
5. Fast and Safe delivery.DHL,EMS,FEDEX,we can accept.
6. OEM are highly welcome.
7. Full range products for choice.
8. Competitive Price,High Quality,Fashion Design,Best Performance.
9. 24 months Warrany,full after-sales services.
